Details
A little bit (cross) country. A little bit rock and roll. The Joplin is a bit of an XC wild child, a light bike that’s heavy on capability with a “let’s go” attitude to any trail.
Let’s go fast. Let’s go far. Let’s go until your legs are ready to give up, and then go some more. Let’s make every second count. Let’s carve rides out of busy days and put those lines on the map on your done list.
The Joplin’s lean frame and 29-inch wheels float over washboard bumps with the same ease it devours jagged ledges. A geometry bred for long days in the saddle is blended with 130mm of travel in the front and 120mm in the rear, creating a capable climber that doesn’t flinch when roots get ragged and rocks start to roll. The lower link VPP suspension offers a responsive pedaling platform that’s ready to get up and go the moment you are. Whether you’re flossing rock gardens or making the rider in front of you your next hare, the Joplin is one rapid trail fox that will take you farther than you thought you could and give you the confidence to go bigger than you thought you would.
With a size range that starts at XS, this bike brings big-wheel benefits to those of us in the fun-size category, too. And yes, every size in the line fits a water bottle inside the main triangle because XS doesn’t mean “do things by half”. Tying up the package is a range of component builds that weave the line between fun and fast, creating a bike that’s ready to race the distance or just race the clouds home.
So, what are you waiting for? Let’s go!
- Carbon CC frame
- RockShox Pike Ultimate 130mm fork
- FOX Float Factory DPS rear shock
- Santa Cruz Reserve 27 Carbon 29-inch rims
- Maxxis Minion tires
- 12-speed SRAM X01 Eagle drivetrain
- RockShox Reverb Stealth dropper seatpost
A dropper seatpost allows you to quickly lower and raise your seat to give you an ideal riding position. Dropping your seat creates a lower center of gravity for better control and maneuverability on steep descents, while raising it puts you at normal riding height for efficient pedaling.
Construction can include either hydraulic- or cable-actuated systems and the post’s travel can either be infinitely adjustable or stopped at set intervals, depending on the model.
Dropper seatposts come in standard lengths and diameters and vary by the amount of travel.
Pedals sold separately
Specs
Frame | Carbon CC 29" 120mm Travel VPP |
---|---|
Fork | RockShox Pike Ultimate, 130mm, 29" |
Headset | Cane Creek 40 IS Integrated |
Rear Shock | FOX Float Factory DPS |
Rims/Wheels | Reserve 27 29" Carbon |
Hubs |
Front: DT Swiss 350, 15 x 110, Torque Cap, 28h Rear: DT Swiss 350, 12 x 148, XD, 28h |
Spokes | Sapim D-Light |
Tires |
Front: Maxxis Minion DHF, 29 x 2.3", 3C EXO TR Rear: Maxxis Minion DHR II 29 x 2.3" EXO TR |
Crankset | SRAM X1 Eagle 148 DUB |
Chainrings | 30T |
Bottom Bracket | SRAM DUB 68/73mm |
Chain | SRAM X01 Eagle, 12spd |
Rear Derailleur | SRAM X01 Eagle, 12spd |
Cassette/Rear Cogs | SRAM XG1295 Eagle, 12spd, 10-52t |
Shifters | SRAM X01 Eagle, 12spd |
Handlebars | Santa Cruz Bicycles Carbon Riser |
Tape/Grips | Juliana Grip |
Stem | Burgtec Enduro MK3 |
Brakes | SRAM G2 RSC |
Saddle | Juliana Primiero |
Seat Post | RockShox Reverb Stealth |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Mist / X-Small | 192219168777 | 58-21219-115-1-721-474602 | 210000109023 |
